Modern Steel Fire Door with Glass Window Finished Surface for for Commercial Use with Fire Prevention

????Ʒ???

Application: Supermarket, Farmhouse, Laundry, Workshop, Warehouse, Home Office, Outdoor, Park, Office Building

Position: Commercial

Type: fire doors

Feature: fire prevention

Door Material: Steel

Opening Method: Manual

Special Door Type: 0

Design Style: Modern

Main Material: Steel

Material: steel

Sliding Door Type: 0

Surface Finishing: Finished

Warranty: 3 Years

After-sale Service: Online Technical Support

Project Solution Capability: total solution for projects, 3D model design, Others, Cross Categories Consolidation, graphic design

Door Type: Glass

Screen Netting Material: Stainless Steel

Place of Origin: Chongqing, China

Brand Name: MEXIN

Certificate: WHI,UL&CE

Color: RAL COLOR

Glass: Fire rated glass

Open Style: Swing

Selling Units: Single item

Brand: Mexin /Customer's Specified Brand

Fire rated: 180 min. CE Fire Rated Door

Certifications: CE certificate

Standard: CE 3H Fireproof

Limitations: Single Swing(Maximum Sizes) 45 mm (1.75 inches) Minimum Thickness 1208 mm (48 inches) Maximum Width 2416 mm (96 inches) Maximum Height Pairs(Maximum Sizes) 45 mm (1.75 inches) Minimum Thickness 2416 mm (96 inches) (each leaf: 1208 mm (48 inches)) Maximum Width 2416 mm (96 inches) Maximum Height

Filling Material: Rock Wool

Louvers: maximum 576 sq. inches (24" x 24") for up to 90 Minute locations. Requires the use of minimum 18 ga. steel channel reinforcement attached to both faces around the louver cutout.

Vision Panels: maximum 1296 sq. inches for 20 and 45 minute locations; 100 sq inches for 60 and 90 Minute locations. Glazing kit for light kits requires use of minimum 18 ga. steel channel reinforcement attached to both faces around the vision panel cutout.

Package: Wooden pallet/ Carton

Surface finish: Paint/Powder coating/Heat transfer

Standard fireproof hardware accessories: CE hardwares

Features: 1¾" standard; also available in 1 3/8" Any manufacturer's hinge locations 18-gauge A60 galvannealed steel standard Continuously welded vertical edges (seamless) standard Rust inhibitive prime coat ANSI/SDI 250.10 Also available as a stock door

Material Options: 16-gauge, 14-gauge and 12-gauge steel G90 galvanized steel Stainless steel Resin impregnated honeycomb

Other Options: Up to 3 hour fire label Integral lite option Integral louver option Flush top cap Any manufacturer's Deadlock prep, Panic
